BARNES JUNIOR BANDSAW

Motor: 1.5 kw Brake Motor 41v, 3 phase

Electrical: 24v switching control 3 switches 1 push to start.

Controls: 1 push to stop, 1 emergency latch-in stop button.

Capacity: Cutting clearance 275mm high x 305mm wide.

Cutting Table: One piece 590mm x 810mm heavy duty 2.5mm stainless steel.

Blade Size: 12 x 2870mm

Blade Speed:  670 m/min or 2200 ft/min.
Wheels: Balanced, Corrosion Resistant aluminum wheels.

Construction: Full 304 food grade stainless steel, smooth grain finish.

Weight: 160 kg

Dimensions: Height 1725mm

Floor Area: 670mm x 860mm

HTB-Junior Bandsaw
BARNES BLADEMASTER MK1 BANDSAW

Motor: 1.5 kw Brake Motor 415v, 3 phase.

Electrical: 24v switching control. 3 switches – 1 push to start.

Controls: 1 push to stop, 1 emergency latch-in stop button.

Capacity: Cutting clearance 405mm high x 435mm wide.

Cutting Table: One piece 825mm x 865mm heavy duty 2.5mm stainless steel.

Blade Speed: 1070 m/min (3500 ft /minute)

Saw Blade: 13mm wide 3600 mm long

Blade Tension: Fully automaticWheels: Balanced, Corrosion Resistant aluminium wheels.

Construction: Full 304 food grade stainless steel, smooth grain finish.

Weight: 240 kg.

Dimensions: Height 1945mm

Floor Area: 990mm x 890mm

HTB-Blademaster-MK1
